Right / Windows permission
|
Read & execute
|
Modify
|
Delete denied
|
|
Read
|
X
|
|
|
|
Update no delete
|
X
|
X
|
X
|
|
Update and delete
|
X
|
X
|
|
|
File
|
Location
|
Administrator rights
|
User rights
|
|
*.must
|
Parent license folder containing a .must license file (ex: License-Y999.must)
Example:
\\server001\Apps\Licenses
|
Update and delete
|
Update no delete
|
|
*.*
|
License subfolder (hidden, created dynamically when license is used)
Example:
\\server001\Apps\Licenses\License-Y999
|
Update and delete
|
Update and delete 1
|
|
File
|
Location
|
Administrator rights
|
User rights
|
|
*.elf
|
Parent license folder containing the .elf license file (ex: L1345.elf).
Example:
\\server001\Apps\Licenses
|
Update and delete
|
Read
|
|
File
|
Location
|
Administrator rights
|
User rights
|
|
*.*
|
Shared configuration folder containing the megasite.ini file. Example: =\\mega\data\config
|
Update and delete
|
Update no delete
|
|
File
|
Location
|
Administrator rights
|
User rights
|
|
*.*
|
<Installation folder> and subfolders (Documentation, Install, java, Mega_Std, System, Utilities)
Main programs
|
Update and delete
|
Read
|
|
*.*
|
<Installation folder>\Cfg
|
Update and delete
|
Read (1)
|
|
*.*
|
<Installation folder>\java\lib_usr
|
Update and delete
|
Read (1)
|
|
*.*
|
<Installation folder>\Mega_Usr
|
Update and delete
|
Read (1)
|
|
*.*
|
<Installation folder>\Utilities\Solution Pack
|
Update and delete
|
Read (1)
|
|
File
|
Location
|
Administrator rights
|
User rights
|
|
*.*
|
<Environment folder>
Environment main folder.
|
Update and delete
|
Read
|
|
*.*
|
<Environment folder>\Db
Root repository folders.
|
Update and delete
|
Read
|
|
*.*
|
<Environment folder>\Db\<Repository>
Repository folder.
• If the repository is stored in the GBMS storage format (default), each HOPEX Repository consists of 4 files (.EMA, .EMB, .EMS, EMV).
• If the repository is stored in Oracle, each HOPEX Repository consists of 2 files (. EMV, .EMO) and files on the database server.
• If the repository is stored in SQL Server, each HOPEX Repository consists of 2 files (. EMV, .EMQ) and files on the database server.
|
Update and delete
|
Update no delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\<Approve>
Default folder for reports (MS Word) detached from HOPEX. This folder can be configured.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\Document
Default folder reports (MS Word). This folder can be configured.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\<Repository>.Lock
Folder of data repository locks for GBMS storage. One file (.EMK) per lock placed. These files can be created and deleted during use of HOPEX
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\<Repository>.Log
Folder of data repository logfile. One file (.MGL) per administration session or per private workspace dispatched. These files can be created and deleted during use of HOPEX.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\<Repository>.Transactions
Folder of private workspace for data repositories (for GBMS storage only) and repository backup logfile.
If the repository is stored in the GBMS format (default), each private workspace consists in two files (.EMB and .EMS). These files are created on opening a private workspace and deleted at each dispatch.
One file (.MGL) per administration session or per private workspace dispatched. These files can be created and deleted during use of HOPEX.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\USER and sub-folders
Personal folders of the users.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Db\<Repository>\WORK and sub-folders
Working folder for administration of repository.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Intranet
Default root folder for static HTML page generation.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\Mega_user
Folder containing customized resources (.MGS, .DOT files)
|
Update and delete
|
Read
|
|
*.*
|
<Environment folder>\SysDb
Folder of system repository. It consists of 4 files (SystemDb.ema, SystemDb.emb, SystemDb.ems, SystemDb.emv)
|
Update and delete
|
Update no delete
|
|
*.*
|
<Environment folder>\SysDb\SystemDb.Log
Folder of system repository logfile. One file (.MGL) per administration session or per private workspace dispatched. These files can be created and deleted during use of HOPEX.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\SysDb\SystemDb.Lock
Folder of system repository locks for GBMS storage. One file (.EMK) per lock placed. These files can be created and deleted during use of HOPEX.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\SysDb\SystemDb.Transactions
Folder of private workspaces for system repository (for GBMS storage only) and repository backup logfile.
If the repository is stored in the GBMS format (default), each private workspace consists in two files (.EMB and .EMS). These files are created on opening a private workspace and deleted at each dispatch.
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\SysDb\USER and sub-folders
Folder of user reports (<user code>.TXT)
|
Update and delete
|
Update and delete
|
|
*.*
|
<Environment folder>\SysDb\WORK and sub-folders
Working folder for administration of system repository.
|
Update and delete
|
Update and delete
|
|
Program feature
|
Comment
|
Installation feature (internal)
|
|
HOPEX (IIS)
|
Installs IIS application 'HOPEX' and 'HOPEX2' in IIS
|
_00_MEGA_HOPEX
|
|
Register MEGA HOPEX in IIS server of machine
|
Complete registration of HOPEX (IIS)
Check it if HOPEX (IIS) is checked
|
_00_HOPEX_IIS_Register
|
|
MEGA Site Service Provider
|
Installs SSP component/service
|
_00_MEGA_SITE_SERVICE_PROVIDER
|
|
MEGA Web Access for Hopex
|
Installs IIS application 'HOPEXAPI'
|
_00_MEGA_HOPEX_MWAS
|
|
HOPEX API
|
Installs IIS application 'HOPEXAPI'
|
_00_MEGA_HOPEX_API
|
|
MEGA Web Access for Hopex API
|
Installs IIS application 'HOPEXAPIMWAS'
|
_00_MEGA_HOPEX_API_MWAS
|
|
MEGA Software
|
Install the HOPEX Programs
|
MEGA
|
|
Administration Program
|
Installs a launcher Administration.exe in the root folder
|
Administration.exe
|
|
MUST License Management Program
|
Installs a launcher licensing.exe in the root folder
|
Licensing.exe
|
|
Utilities
|
Installs utilities in a folder '\Utilities'
|
See table below
|
|
MEGA Documentation
|
Installs documentation in PDF format
|
Documentation
|
|
Debugging files
|
Installs additional files for debugging purpose
|
MEGA.DebugSymbol
|
Installation feature (internal) | Comment | Target folder | Install Level |
Administration.exe | Installs Administration.exe | INSTALLDIR | 100 |
Data.Extractor | Installs MEGA Data Extractor utility | INSTALLDIR\Utilities\MEGA Data Extractor | 300 |
Documentation | Installs documentation | INSTALLDIR\Documentation | 200 |
EnvComparator | Installs MEGA Customisation Analyser utility | INSTALLDIR\Utilities\MEGA Customisation Analyser | 300 |
Install | Installs the folders 'Advance Reporting', 'Compatibility Tools', 'Doors', 'Languages' | INSTALLDIR\Install | 200 |
Install.DBMS | Install RDBMS related resources | INSTALLDIR\Install\RDBMS client | 200 |
Install.Licenses | Installs the folder 'Licenses' | INSTALLDIR\Install\Licenses | 200 |
Install._GR | Installs the _GR files, Upgrade files, preinstalled SystemDb (GBMS), predefined system business documents | INSTALLDIR\Install | 200 |
Licensing.exe | Install Licensing.exe | INSTALLDIR | 100 |
MEGA | Installs HOPEX.exe, binary files and resources (folders 'java', 'Mega_std', 'System' and '\Utilities\Solution Pack') | INSTALLDIR | 100 |
MEGA.DebugSymbol | Install PDB files (optional) | INSTALLDIR\System | 600 |
Optional.File | Installs optional .mol files | INSTALLDIR\Mega_Std | 200 |
Optional.Moka_Reference | Installs MOKA related resources | INSTALLDIR\Mega_Std\Moka Reference | 200 |
RDBMS_Diagnostic | Installs RDBMS Diagnostic tool | INSTALLDIR\Utilities\RDBMS Diagnostic | 300 |
System.FlexGrid | Redistributable file system Microsoft FlexGrid | %systemroot% | 100 |
System.GDIplus | Redistributable file system Microsoft GDI + | %systemroot% | 100 |
System.MSXML | Redistributable file MS XML3 | %systemroot% | 100 |
System.Redist | Redistributable file system | %systemroot% | 100 |
System.Scripting56 | Redistributable file system Windows Scripting Host 5.6 | %systemroot% | 100 |
System.VB6 | Redistributable file system VB6 Runtime | %systemroot% | 1 |
System.VC10 | Redistributable file system VC10 | %systemroot% | 1 |
System.VC8 | Redistributable file system VC8 | %systemroot% | 100 |
System.WData | Redistributable file system WebData std library | %systemroot% | 100 |
Test.Utilities | Installs utilities: HOPEX Server Supervisor utility, RDBMS Diagnostics… | INSTALLDIR\Utilities | 300 |
Utilities | Installs utilities and resources: MEGA Mail Test utility, transport order (Solman) | INSTALLDIR\Utilities | 300 |
_00_HOPEX_IIS_Register | Registers IIS application 'HOPEX' in IIS | <registry> | 900 |
_00_MEGA_HOPEX | Installs IIS application 'HOPEX' and 'HOPEX2' in IIS | IISROOT\wwwroot\HOPEX | 400 |
_00_MEGA_HOPEX_MWAS | Installs IIS application 'HOPEXMWAS' in IIS Installs service 'Mega Service Watchdog' | IISROOT\wwwroot\HOPEXMWAS IISROOT \wwwroot\MegaMSW <registry> | 400 |
_00_MEGA_SITE_SERVICE_PROVIDER | Installs IIS application 'MegaSSP’ in IIS Installs services 'Mega Site Service Provider and 'Mega Service Watchdog' | IISROOT\wwwroot\MegaSSP <registry> | 400 |
_00_MEGA_HOPEX_API | Installs 'HOPEX API | IISROOT\wwwroot\HOPEXAPI | 400 |
_00_MEGA_HOPEX_API_MWAS | Install ' MEGA web Access for HOPEX API ' | IISROOT\wwwroot\HOPEXAPIMWAS | 400 |
